- Recommended range of use : +5 to 30°C.
- Possible range of use : -30 to 60°C.
- Maximum static pressure : 14 bars.
- Manometer body : 20 mm thick PVC
- Liquid column :
- tube Ø 4 x 10 mm in Altuglas for mercury.
- tube Ø 6 x 10 mm for VF1.
- Graduated slide strip : transparent Altuglas. Cross-section 54 x 3 mm.
- Zero adjustment by moving the graduated slide strip, travel 20 mm. Fixed in place via milled, nickel-plated brass screw.
- Connection : Ø 5×8 mm semi-rigid crystal tube on Ø 6.2 Delrin ribbed connectors with M 7×100 thread.
- Wall mounting via two Ø 5 mm screws.
Measurement Range :
A : 125-0-125 • 250-0-250 • 350-0-350 • 500-0-500 B : 170-0-170 • 340-0-340 • 470-0-470 • 670-0-670
