- Air duct for the investigation of the heat transfer in airflows
- Use of different heat exchangers in the air duct
- Insulated air duct with flow straightener
- Radial fan with adjustable flow rate
- Pitot tube with inclined tube manometer to measure velocitiy distribution and pressure loss
- Pressure sensor, combined temperature and humidity sensor
- Switch cabinet with digital displays
Technical Data
- Air duct cross-section: 150x300mm
Fan
- power: 900W
- max. flow rate: 1680m³/h
- max. pressure difference 1000Pa
- nominal speed: 2840min-1
- Pitot tube: travel 300mm
- Inclined tube manometer: 0…100Pa
Sensor Measuring Ranges
- temperature: 2x 0…50°C
- humidity: 2x 100% rel. humidity
- pressure: 2x 0…10mbar
