Features: The board consists of the following built-in parts :
- + 5V D.C. at 500mA, IC Regulated Power Supply internally connected.
- Two, 3-input NAND gates followed by an inverter to give 3-input AND/NAND gates.
- Two, 3-input NOR gates followed by an inverter to give 3-input OR/NOR gates.
- Two, NOT gates followed by another NOT gate to give BUFFER outputs.
- Switches for logic selection.
- LEDs for visual indication of status.
- Adequate no. of other Electronic Components.
- Mains ON/OFF switch, Fuse and Jewel light.
- The unit is operative on 230V ±10% at 50Hz A.C. Mains.
- Adequate no. of patch cords stackable from rear both ends 4mm spring loaded plug length ½ metre.
- Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections / observation of waveforms.
- Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References.
- Weight : 3 Kg. (Approx.)
- Dimension : W 340 x H 110 x D 210
