Drinking Water Pilot
Teaching Objectives of
Drinking Water Pilot
- Analysis with industrial sensors of chlorine, turbidity at the output of the decanter or filters, pH measurement.
Technical specifications
- A turbidity sensor and transmitter.
- Four solenoid valves.
- Three tanks.
- Three peristaltic pumps.
- A stirrer.
- Decanting tank adaptor for installing the turbidity sensor.
- Adaptor at the base of the filtration column for the turbidity sensor.
- Tank for treated product.
- Alarms with two levels on high and low alarms.
- Control panel with all controls.
- Alarms with two levels on high and low alarms.
Dimensions
- 4000 x 800 x 2000 mm
Essential requirements
- Solution of CuSO4 10-3 M with lime (50 mg/l),
- Sand bed : H = 60 cm – Int diam = 10 cm Granule size : 0.8 < d < 1 mm.
- Flocculation – Decanting of CuSO4 with lime. Starch – FeCl3.
- Power supply : 220 V / single phase / 50 Hz
