Features :
- LSI-circuit provides high reliability & durability
- Measurement : Watt, ACV, ACA and Power factor
- 8 x 8.5mm large LCD and Max. reading 9999
- Fully Auto range and zero adjustment facility
- Memory record, recall and data hold function
- Built in low battery indicator
Technical Specifications :
- Watt ( True power ) : 0 ~ 6000 W
- Accuracy : ±(1%+5W), Resolution : 1W
- ACV (True RMS) Range : 0 ~ 600V
- Accuracy : ±(0.3% + 0.3V) Resolution : 0.1V
- ACV input impedance : 10MΩ
- ACA ( True RMS ) range : 0.01 ~ 10A
Accuracy : ±(0.3% + 0.03A) Resolution : 0.01A
- Power factor range : 0.01 ~ 1.00
- Accuracy : ±(1% + 2d), Resolution : 0.01
- Data output : RS 232 / USB PC interface
- Sampling time : Approx. 1 second
- Dual value display with backlight facility
- Power : DC 9 V Battery
